MicroCaster microarray system, MicroCaster System, 8-pin system hand tool, MicroCaster 8-pin system

Stock Code: 2796147
Manufacturer Part No: Z721239-1EA

Order Now for 7 day delivery

Click Add to Quote for price and delivery

Quantity: - +

Descriptions

General description

Handheld Microarraying SystemThe MicroCaster is an economical, entry-level manual microarraying system for principle and pilot studies. With the MicroCaster 8-pin hand tool, samples can be loaded from 96 well or 384 well microtiter plates.The MicroCaster slide holder accommodates two slides. It has a built-in indexing system that enables precise printing of up to 768 spots in an array of 32 x 24 spots. It is very easy to set up and use with processing time of 5 to 20 minutes per slide.The MicroCaster is designed for 1-pad FAST Slides with 20 x 51 mm pad size and is compatible with other slide surfaces.MicroCaster accessories can be used to increase the flexibility of the manual arrayer system by providing accurate source-plate indexing and reliable pin-tool cleaning.The MicroCaster accessories are compatible with standard 96 well microplates and they reduce hassle with pin-tool cleaning.Specifications: Number of spots: up to 768 Horizontal pitch: x-axis 1250 µm Vertical pitch: y-axis 750 µm Spot size: 500 to 1000 µm Print volume: (varies with buffer and viscosity) 20 to 70 nL

MicroCaster System includes:MicroCaster 8-Pin System Hand ToolMicroCaster 8-Pin System Slide HolderMicroCaster Pin ConditionerSpare Replicator Pins

Other Notes

Field of Use : For internal research use only. Products are not intended for diagnostic use or resale.
